MPPT SOLAR PCU 2kW/36V
Actual Price : Rs. 228,325.00
Selling Price : Rs. 194,076.25
Selling Price : Rs. 194,076.25
- MPPT based State-of-the-art Latest Technology for Optimum Performance.
- Pure Sine wave Output to run all Sophisticated Appliances.
- User-Friendly LCD Display.
- Operates on both Solar Power as well as Grid Power.
- Intelligent Sharing of Grid Current with Solar in case of Solar Energy Shortfall.
- MPPT with Intelli Current Boost Technology.
- Designed to give maximum benefit from Solar Energy & minimize your Electricity Bill.
- Priority Selection Option for Solar / Battery / Grid
- Peak Output Power handling capacity.
- Intelli Overload sense with Short Circuit Protection.
- Battery Deep Discharge Pickup Capability.
- Grid Charging Enable-Disable setting from the Front Panel to provide “No Charging of Battery from the Grid”.
Technical Details
|
Model |
MPPT BASED SOLAR PCU 2 kW / 36V |
|
Capacity (Rated Power) |
2 kW / 36 V |
|
Capacity (Maximum PV Power support) |
2KWp |
|
Input |
|
|
Input Voltage (Standard Range) |
100 V ~ 300 V |
|
Input Voltage (Narrow Range) |
180V ~ 260 V |
|
Nominal Input Battery Voltage |
36 V |
|
Output |
|
|
Output Frequency |
50 Hz ± 0.5 Hz |
|
Output Waveform |
Pure Sine Wave |
|
Technology |
|
|
Solar Charger Type |
MPPT |
|
Solar Panel VOC (Max) |
60V ~ 170 V DC |
|
Max. Panel Current |
20 Amps |
|
Low Battery Indication |
31.8 V ± 0.6 V DC |
|
Low Battery Shut Down |
31.5 V ± 0.6V DC |
|
Safety Protections |
|
|
Protections |
Low Battery, Low Battery Shutdown, Output Overload, Output Short Circuit with Solar. |
|
Operating Temp. |
0 to 40 Degree Celsius |
|
Relative Humidity /Audible Noise |
0-95% non-condensing/Less than 55dBA (at 1M) |
